Battery Labeling Machine

Xiamen Acey New Energy Technology Co.,Ltd is one of the most reliable manufacturers and suppliers of battery labeling machine in China. Please rest assured to buy high quality products made in China here from our factory. Contact us for customized service.



Cylindrical Battery Auto Sticker Machine





A battery labeling machine is a device used to apply labels, usually paper or plastic, onto the surface of a battery. The device typically consists of a conveyor belt or other moving system, which carries the battery past a labeling station where the label is applied. Labelers often use adhesive or heat-sensitive adhesives to attach the label to the battery. Some machines may also include an inkjet printer for printing information onto labels before they are applied.

Battery labeling machine is a kind of automatic equipment for pasting barley paper on cylindrical batteries. This equipment realizes the function of pasting barley paper onto qualified batteries with simple and generous mechanical structure design and stable system performance.





* The equipment has compact structure design, beautiful appearance and small floor space.
* The equipment is equipped with universal mobile casters, which is easy to move and transport the equipment.





Model No.:	ACEY-BS01
Voltage Supply	single-phase ~ 220V, 50Hz
Rated power	2KW
Surface pad material	highland barley paper or PVC material
batrery type	Cylindrical cell 18650, 21700, 26650, 32650, 32700
Pneumatic pressure	0.4-0.8Mpa barley paper machine
Cushioning power	electric or pneumatic
Control device	7.5 inch touch screen, PLC programmer and servo motor
Barley paper roll width	100mm
Speed	4000-4500PCS/hour, 4PCS per punch
Dimensions	L1110mm*W710mm*H1580mm
Machine weight	200Kg
Feeding method	insert battery cell hopper: 400pcs each time, available for 2 separate inserting units BNX-350 auto pasting
Knife mold	slow-moving wire processing method, high precision, 5000 knife molds are coated once to remove sticky water
Material specification requirements	the max diameter of barley paper roll material is 350MM, the inner diameter of paper roll core is 72-75MM









accessories



Battery Labeler Operation



1. Ensure that all of the components for the labeling process are in place, including stickers, labels, and adhesives.

2. Place the item to be labeled onto the labeler's conveyor belt and adjust any controls to ensure it is properly centered on the belt.

3. Activate the labeler, making sure to follow all safety precautions.

4. Feed the label into the labeler according to the instructions provided in the user manual and adjust any settings as required (e.g., speed).

5. Observe how the labeler applies adhesive and labels to ensure that they are correctly placed on each item being labeled.

6. If necessary, adjust any settings on the machine to ensure accurate placement of labels and adhesive on each item being labeled.

7. Once labeling is complete, remove each item from the machine and inspect for accuracy before packaging and shipping out to customers.
