Lithium Battery Pack Spot Welder
Model No.: ACEY-D300B (Electric version)
Battery Types: 14500/18650/21700/26650/32650/32700
Warranty: 1 year
MOQ: 1 set
Package: Plywood Case
Xiamen Acey New Energy Technology Co.,Ltd is one of the most reliable manufacturers and suppliers of lithium battery pack spot welder in China. Please rest assured to buy high quality products made in China here from our factory. Contact us for customized service.
Lithium Battery Pack Spot Welder
Products Description
ACEY-D300B is suitable for battery pack double-sided spot welding and assembly in the factory for 14500 / 18650 / 21700 / 26650 / 32700 multi-parallel multi-series combination.It can be used in electric tool battery, torsion car battery, Energy Storage Battery Pack, Scooter Electric Vehicle Battery, etc. Compared with manual spot welding, the efficiency and accuracy of welding have been greatly improved. The operation and debugging very easy and convenient. Design of components built-in makes appearance more concise.
- Y-axis stroke: 500mm(customizable)
- X-axis stroke: 350mm(customizable)
- Spot welding speed: 0.35s/ point; 1hour: about 5,500 18650 cells.
- Maximum speed of motor drive: 1000mm/s
- (conventional) maximum load capacity :160pcs(standard 18650 lithium battery)
- Number of recordable file groups: 100
- Operating system: embedded system + man - machine screen
- Transmission mode: step + belt + imported precision linear guide rail (optional servo + screw
Specification
|
Max load electric cores |
X direction: 26; Y direction: 18 |
|
Capable file group storage |
100 groups |
|
Operating system |
embedded system human-machine interface |
|
Transmission mode |
Taiwan precision screw with guide rail |
|
Driving mode |
stepper servo motor |
|
Repeat positioning accuracy |
±0.02mm |
|
Dimensions |
L1020mm*W910mm*H1770mm |
|
Power |
4000W |
|
Machine weight |
350KG |
|
Max bearing weight of Y-axis |
50KG |
|
Input power supply |
single-phase AC 380V/50Hz |
|
Air Source |
0.4-0.6 Mpa |
Products Details
