Roller Press Machine

Xiamen Acey New Energy Technology Co.,Ltd is one of the most reliable manufacturers and suppliers of roller press machine in China. Please rest assured to buy high quality products made in China here from our factory. Contact us for customized service.

Roller Press Machine for Battery Electrode Calendering

Roller Press Machine for Battery Electrode Calendering is aimed at high-precision rolling of positive and negative plates in the battery industry. The equipment has good horizontal and vertical rolling uniformity, and the appearance of the rolled product is high-quality. The equipment is provided by the hydraulic system to provide pressure for roll rolling. It is suitable for Where there is a higher requirement for the consistency of rolling force and rolling gap.

• Integral gantry frame, CNC precision machining to ensure high precision and high stability;
• The roll is made of imported cold-rolled chromium-molybdenum material, and the surface is chromium-plated and cryogenically treated by heat treatment, with high internal and external hardness and good wear resistance;
• The hydraulic system imported from the United States automatically controls the rolling pressure;
• Patent design hydraulic balance rolling mechanism, stable pressure holding, good horizontal and vertical rolling uniformity;
• Slanted block type roll gap adjustment device, display adjustment;
• Surface hardness HRC65~68, internal hardness HRC60-62, roughness Ra≤0.4, round runout better than ±2μm
• The single reduction of the lithium electrode sheet is 20%~30%, if it is thinner, it needs to be rolled several times (5μm/time)
