5V50MA Button Cell Battery Tester
Order(Moq): 1 set
Compliance: CE Certified
Package: Plywood Case
Product Origin: China
Warranty: One-year warranty with lifetime support
Payment: T/T, Western Union, Paypal, Ali Trade Assurance
Xiamen Acey New Energy Technology Co.,Ltd is one of the most reliable manufacturers and suppliers of 5v50ma button cell battery tester in China. Please rest assured to buy high quality products made in China here from our factory. Contact us for customized service.
5V50MA Button Cell Battery Tester for Battery Capacity Testing
Product Description
This coin cell batteryanalyzer is for battery charging, battery discharging, checkingbattery performance, small scale battery formation, capability grading, battery pack testing, etc.
Specification
| Product Name | Battery Testing Equipment 5V50MA | |
| Model No. | ACEY-BT-5V50MA | |
| Input power | AC 220V ±10% / 50Hz | |
| Input active power | 25W | |
| Input Resistance | ≥1MΩ | |
| Resolution | AD：16bit;DA：16bit | |
| Voltage | Per Channel Voltage Range | 25mV~5V |
| Discharge Min Voltage | 0V | |
| Accuracy | ± 0.05% of FS | |
| Stability | ± 0.05% of FS | |
| Current | Per Channel Current Range |
Range one：5uA~1mA; Range two：1mA~25mA; Range three：25mA~50mA |
| Accuracy | ± 0.05% of FS | |
| Constant Voltage Cut-off Current | 2uA;0.05mA;0.1mA | |
| Stability | ± 0.05% of FS | |
| Power | Per Channel Output Power | 0.05W |
| Stability | ±0.1% of FS | |
| Time | Current Response Time | (0~Full Range)＜1ms |
| Step Time Range | ≤(365*24)Hour/Step | |
| Data Recording | Recording Condition |
The minimum time interval：100ms The minimum voltage interval：10mV The minimum current interval：2uA;0.05mA;0.1mA |
| Record Frequency | 10Hz | |
| Charge | Charge Mode | Constant Current Charge,Constant Voltage Charge,Constant Current and Constant Voltage Charge,CPC |
| End Condition | Voltage,Current,Relative Time,Capacity,-△V | |
| Discharge | Discharge Mode | CCD,CPD,CRD |
| End Condition | Voltage,Current,Relative Time,Capacity | |
| Pulse | Charge | CCC |
| Discharge | CCD | |
| Min Pulse Width | 500ms | |
| Pulse Number | Each pulse step supports 32 different pulses | |
| Automated Switch | Automated switch from charge to discharge for each pulse | |
| End Condition | Voltage, Test Time | |
| Cycle | Loop Measure Range | 1~65535 times |
| Max Steps Per Loop | 254 | |
| Nested Loop | Nested loop Function,Max Support 3 Layers | |
| Protection | Software Protection | Power-down Data Protection |
| Off-line Testing Function | ||
| Setting Protection Condition,Setting Parameter：Low Voltage limit,Upper Voltage limit,Low Current limit,Upper Current limit,Delay Time | ||
| Noise | <85dB | |
| Channel Features | Constant Current Source and Constant Voltage Source with Independent pairs of Closed-loop Structure | |
| Channel Control Mode | Independent Control | |
| Voltage and Current Testing Sample | 4-wire connecting | |
| Database | MySQL Database | |
| A Means of Communication of Upper Machine | TCP/IP Protocol | |
| Data Output | EXCEL,TXT,Graph | |
| Communication Interface | Ethernet Port | |
| Per Unit Main Channels No. | 8 | |
| Working Temperature Range | 0℃~40℃ | |
| Storage Temperature Range | -10℃~50℃ | |
| Working Environment Relative Humidity Range | 30% ~ 80% RH | |
| Storage Environment Relative Humidity Range | 30% ~ 90% RH | |
| Dimensions | 1U,W*D*H：480*330*45(mm) | |
Products Details
