PVC POF PE PP Film Automatic Heat Shrink Packing Machine
Item No.: ACEY-4525C
Order(Moq): 1 set
Compliance: CE Certified
Package: Plywood Case
Product Origin: China
Warranty: One-year warranty with lifetime support
Payment: T/T, Western Union, PayPal, Ali Trade Assurance
Xiamen Acey New Energy Technology Co., Ltd. is a manufacturer and supplier of pvc pof pe pp film automatic heat shrink packing machine in China, offering factory-direct supply to customers worldwide. We also provide battery pack assembly equipment and turnkey production lines that comply with applicable CE requirements, along with OEM/ODM services and 24/7 after-sales support. Contact ACEY for product specifications, model selection advice, and a detailed quotation for pvc pof pe pp film automatic heat shrink packing machine.
PVC POF PE PP Film Automatic Heat Shrink Packing Machine
Products Description
The ACEY-4525C is an automatic heat shrink tunnel machine designed for packaging products with PVC, POF, PE, and PP shrink films. It uses a heated air circulation system to shrink the film evenly around products as they pass through the heating tunnel on the conveyor.
The machine features a 1200 × 450 × 250 mm heating tunnel, a 12 kW heating system, and an adjustable conveyor speed of 0–15 m/min. Operators can adjust the conveyor speed and tunnel temperature according to the film type, product dimensions, and packaging requirements.
With a maximum conveyor load of 25 kg, the ACEY-4525C is suitable for continuous shrink packaging of individual products and grouped items. It can be used in lithium battery pack packaging, electronics, hardware, daily necessities, and other applications requiring protective shrink film packaging.
Applications
The ACEY-4525C automatic heat shrink tunnel is suitable for:
- Lithium-ion battery pack shrink film packaging
- Cylindrical battery pack outer film packaging
- Electronic components and electrical products
- Hardware products and small industrial components
- Daily-use products and consumer goods
- Individual or grouped product shrink packaging
For battery pack applications, the machine can be used in the final packaging stage after the battery pack has been assembled and the shrink film has been placed around the product.
Features
1. Compatible with Multiple Shrink Films
Supports PVC, POF, PE, and PP shrink films, providing flexibility for different product packaging requirements.
2. Adjustable Conveyor Speed
An electronic speed controller allows operators to adjust conveyor speed from 0 to 15 m/min according to product size and shrink film characteristics.
3. Stainless Steel Heating Elements
Equipped with stainless steel heating elements to provide rapid heating and support continuous shrink packaging operations.
4. Hot Air Circulation System
A high-power air circulation motor helps distribute heated air throughout the tunnel, promoting more uniform film shrinking.
Specification
|
Power supply: |
380V50-60HZ |
|
Power: |
12KW |
|
Dimensions: |
1200mm x 450mm x 250mm |
|
Transporting velocity: |
0-15m/min |
|
Conveying material: |
Mesh |
|
Conveyor loading: |
25kg max |
|
Machine size (l * W * H): |
1600mm x700mm x1520mm (L* W * H) |
|
Weight: |
185kg |
|
Shrink film: |
PE,POF,PVC,PP |
Product Detail
Frequently Asked Questions
Q1: What types of shrink film can the ACEY-4525C process?
The machine is compatible with PVC, POF, PE, and PP shrink films. The appropriate film should be selected according to the product's packaging requirements and the film manufacturer's recommended shrinking conditions.
Q2: Can this heat shrink tunnel machine be used for lithium battery pack packaging?
Yes. It can be used to shrink protective film around assembled lithium battery packs, including cylindrical battery packs. The product dimensions and packaging method should be checked against the tunnel opening and conveyor capacity.
Q3: Can I adjust the conveyor speed and heating temperature?
Yes. The conveyor speed can be adjusted from 0 to 15 m/min. The heating temperature can also be adjusted to suit different films and products.
Q4: What is the maximum weight this heat shrink machine can carry?
The maximum conveyor loading capacity is 25 kg. Please also consider the dimensions and shape of the product to ensure stable transportation through the tunnel.
Q5: How do I choose the right heat shrink machine for my products?
When selecting a machine, consider the product length, width, height, weight, shrink film type, required packaging speed, and available power supply. These details help determine whether the ACEY-4525C is suitable for your application.
Looking for an automatic heat shrink tunnel machine for battery packs or other industrial products?
Send ACEY your product dimensions, shrink film type, and packaging requirements. Our team can help evaluate the machine configuration and provide a suitable equipment recommendation and quotation.
