Name: China Customized 5V 1000A Battery Charge Discharge Tester Manufacturers Suppliers - Acey New Energy
Brand: Acey
SKU: 233781915

Item: 5V 1000A 2 Channels Battery Charge Discharge Tester
Model No.: ACEY-HRCDS-5V1000A-2CH
Battery Type: Li-ion battery, lead-acid battery, Ni-Cd battery, NiMH battery and so on
Warranty: 1 year
MOQ: 1 set
Package: Plywood Case

Send Inquiry

Product Introduction

Xiamen Acey New Energy Technology Co.,Ltd is one of the most reliable manufacturers and suppliers of 5v 1000a battery charge discharge tester in China. Please rest assured to buy high quality products made in China here from our factory. Contact us for customized service.

5V 1000A 2 Channel Battery Charge Discharge Tester

Equipment configuration list

No.	Category	Product name	Product model	Quantity	Remarks
1	Test equipment	Charge and discharge test equipment	ACEY-HRCDS-5V1000A-2CH	2CH
2	Cabinet	Charging and discharging equipment cabinet	/	1PCS	Default without power input line
3	Computer	Computer	Dell computer I5-10500 processor /16G memory / 256G solid state + 1T hard disk / 3 network port	1PCS	Optional,including mouse, keyboard and 19 inch AOC displayer
4	Accessories	Charge discharge test line	/	2PCS	Each channel has a set of test lines with a length of 3.5meters.(including fixture)
5	Accessories	Switch	TP-LINK TL-SF1008VE	1PCS
6	Accessories	Communication accessories	Communication line / Crystal head, etc	Several	For communication
7	Accessories	USB Flash Drive	16G	1PCS	Contains Test software etc.
8	Accessories	File	/	1PCS	Test report, packing list, etc

Application and function

Application: This battery charge discharge tester is mainly used for circle life testing and quality control of li-ion battery, lead-acid battery, Ni-Cd battery, NiMH battery and so on in production line or in lab.
Support battery circle life testing, capacity testing, charging characteristic testing, discharging characteristic testing, charge retention capability testing, charge and discharge efficiency testing, over charge or over discharge rate affordability testing.

Working environment and technical parameter

Stand alone power supply: AC 220V±10%, frequency: 50HZ±5%.
Power supply of the whole cabinet: AC 380V±10%, frequency: 50HZ±5%.
Maximum input power of the whole cabinet: 14.3 kW (2CH)
Working temperature: 0℃~ 45℃.
Humidity: less than ≤ 85%R.H (non-condensing).
No severe shake, no corrosive gases, no flammable or explosive gases around.
Resolution: AD 16 bit.

No.	Item		ACEY-HRCDS-5V1000A-2CH
1	Main channels		1CH/ module
2	Channel working mode		Completely independent.
3	Main channel working mode		Charge: CC, CV, CCCV, no voltage or current impact when CC transfer to CV.
			Discharge: CD, CP, CR, DCCV.
			Still, Pulse test, Working Condition test, DCIR test.
	Main channel test cutoff condition		Time, total voltage, total current, capacity, -ΔV, Vcell, RSOC, etc.
4	Main channel Voltage	Single channel test range	0V-5V
		Min. discharge voltage	1V
		Accuracy	±0.05%FS+0.05%RD
		Resolution	0.1mV
	Main channel Current	Single channel test range	±1000A
		Min. output current	500mA
		Accuracy	±0.05%FS+0.05%RD
		Resolution	1mA
		Current start response time	＜20ms(10%FS~90%FS)
	Time	Resolution	10mS
	Auxiliary temperature (Optional)	Range	﹣20℃～100℃
		Accuracy	±1℃(0℃～70℃)
		Resolution	0.1℃
	Power	Output power	Single channel continuous working power 5000W
		Stability	±0.1%FS+0.1%RD
5	Communication		LAN
6	Control program		Support data protection when power off, continue testing caused of power cutoff or manually stop and revise step parameter online.
			Users can set protection condition, include minimum voltage, maximum voltage, minimum current, maximum current, etc.
			Users can set auxiliary channel protection condition, including minimum voltage, maximum voltage, maximum temperature, minimum temperature.
			Cycle time	Max. 9999
			Programmable step	Max. 9999
			Nested loop	Max. 10 layers
			Step time range	No limit, support h, min, s
			Data record	Time≥10ms,Voltage≥0.05%FS+0.05%RD,Current≥0.05%FS+0.05%RD
			Program feature	Each step has one or multiple exit
7	Data display		Cycle list	Circulation number. Charge/discharge capacity, efficiency, power and average voltage, etc.
			Process list	Process number, working mode, process time, capacity, power, DIR, medium voltage, cut-off voltage, cut-off current, etc.
			Detail list	Record number, system time, cumulative time, voltage, current, energy, power, cell temperature, etc.
8	Data export		Data can be exported as EXCEL, TXT or diagram. Provide charge discharge efficiency, charge discharge curve, voltage, capacity, current-time characteristic curves, etc.
9	Data saving		Save as files
10	Curves type		X-coordinate: total time, charge discharge capacity, cycle time, voltage, current, capacity.
			Y-coordinate: total voltage, current, capacity, power, cell temperature(Optional), end of charge and discharge capacity, etc.
11	Software protection		Power off data protection, power resume continue testing, OVP, ODP, OCP, UCP, OTP, capacity protection, abnormal voltage trend protection, abnormal current trend protection, abnormal current fluctuation protection, abnormal voltage fluctuation protection, abnormal charging voltage increase rate protection, abnormal discharge current decrease rate protection.
	Hardware protection		Power off, open circuit and short circuit protection. Reverse or wrong connection protection, OCP, OVP, OTP, fixture contact abnormal protection.
	Warning function		Switch off automatically under emergency, shutdown when power off, load connect and disconnect automatically.
12	Barcode scan		Support barcode start and binding test data, classify batteries rapidly and accurately. Support detailed battery database management functions, connect battery information with testing data base, which is easy for management of data base system.
13	Sampling terminals		Four-polar sampling. Copper nose or other fixture.
14	Energy consumption		Discharge power feedback to grid
15	Cooling method		Forced Fan-cooled
	Noise		Less than 70dB
	IP grade		IP20
16	Repair		Modularized structure. Can be replaced or repair with spare parts.
