Lithium Battery Stacking Machine
Back view of Battery Stacking Machine
Front view of Battery Stacking Machine
Pouch Cell Stacking Machine

Lithium Battery Stacking Machine

Name: China Lithium Battery Stacking Machine Manufacturers Suppliers - Customized Service - Acey New Energy
Brand: Acey
SKU: 215285396

Item No.: ACEY-SSM-A
Order(Moq): 1 set
Compliance: CE Certified
Package: Plywood Case
Product Origin: China
Warranty: One-year warranty with lifetime support
Payment: T/T, Western Union, Paypal, Ali Trade Assurance

Send Inquiry

Product Introduction

Xiamen Acey New Energy Technology Co., Ltd. is a manufacturer and supplier of lithium battery stacking machine in China, offering factory-direct supply to customers worldwide. We also provide battery pack assembly equipment and turnkey production lines that comply with applicable CE requirements, along with OEM/ODM services and 24/7 after-sales support. Contact ACEY for product specifications, model selection advice, and a detailed quotation for lithium battery stacking machine.

Manual Lithium Battery Stacking Machine For Pouch Cell

Product Description

Manual Lithium Battery Stacking Machine For Pouch Cell is suitable for the lamination process of battery cells, zigzag the positive and negative electrodes and the diaphragm.

Features

The adjustment, operation and maintenance of the machine are simple and easy.
Applicable to a wide range of cell stack sizes.
High working efficiency, with digital display counter.
Adopt foot switch to control cylinder movement.
The machine is small in size, exquisite and beautiful in appearance.

Specification

Model No.	ACEY-SSM-A
Lamination method	Z-shaped lamination
Diaphragm material roll	roll material diaphragm, 3 inch core, diameter φ200mm
Applicable pole piece specifications	length (20～200) mm, width (20～200) mm, thickness within 16mm
Swing roller travel stroke	300mm
Power supply	AC220V/50Hz
Power	200W
Air pressure source	0.4MPa～0.7MPa
Equipment size	L650mmW400mmH700mm
Control box size	L200mmW300mmH380mm
Weight	30Kg
